Caproni

• 00 Gear Pump: displacement: 0.25 to 2 cm³. Outlet pressure: up 200 bar. Speed: 750 to 3500 rev/min. Fluid temperature: -20 to +80 °C. Working liquid: hydraulic oils. Viscosity: 16 to 200 mm²/s. Degree of filtration: 15-25µm;
• 10 Gear Pump: displacement: 1 to 9.8 cm³. Outlet pressure: 250 bar. Speed: 650 to 3500 rev/min. Fluid temperature: -20 to +80 °C. Working liquid: hydraulic oils. Viscosity: 20 to 200 mm²/s. Degree of filtration: 25µm;
• 20 Gear Pump: displacement: 4.5 to 36 cm³. Outlet pressure: 250 bar. Speed: 650 to 3500 rev/min. Fluid temperature: -20 to +80 °C. Working liquid: hydraulic oils. Viscosity: 20 to 200 mm²/s. Degree of filtration: 25µm;
• 30 Gear Pump: displacement: 20 to 60 cm³. Outlet pressure: 250 bar. Speed: 650 to 2500 rev/min. Fluid temperature: -20 to +80 °C. Working liquid: hydraulic oils. Viscosity: 20 to 200 mm²/s. Degree of filtration: 25µm;
• Caproni pumps with valves: technical characteristics are in line with those of the Group 10, 20 and 30 pump groups;
• Tandem pumps: technical characteristics are determined by the compound gear pumps.

Caproni Control Valves

• Caproni sectional control valves: rated flow: 80 l/min. Rated pressure: 250 bars. Maximum back pressure: 18 bars. Nominal port size: 12 mm. Fluid temperature: -20 to +80 °C. Working liquid: hydraulic oils. Viscosity: 15 to 300 mm²/s.
• Directional control valves: maximum pressure: Port P, A and B: 320 bars, Port T: 160 bars. Maximum flow: NG06 – 80 litres/minute, NG10 – 140 l/min. Fluid temperature: -20 to +80 °C. Working liquid: hydraulic oils. Viscosity: 10 to 800 mm²/s.

Caproni Valves

• Caproni valves for modular pipe and plate mounting: relief, relief-prefill, unloading relief, pressure reduction, check, flow control, dividing and combining valves. Nominal bore: 6, 10 mm, pressure control range: 5 to 100 bar, 15 to 200 bar, 20 to 320 bar, rated flow: 10 to  160 litres/minute, working temperature: -20 to +70 °C, working liquid: hydraulic oils, viscosity: 10 to 200 mm²/s, degree of filtration: 25µm
• Cartridge valves: solenoid, relief, sequence, needle, manual, pressure reduction Valves. Operating pressure: 250 bars, internal leakage: 0.22 cc/min at 250 bars, fluid temperature: -20 to +90 °C, working liquid: hydraulic oils, viscosity: 10 to 800 mm²/s, degree of filtration: 25µm.

Caproni Hydraulic Systems

• Caproni EI mini power packs: AC motors 0.55 to 3 kW, mono or three-phase, DC 0.8 to 3 kW; 12 or 24 V, Tank volume: 1 to 60 litres, pump displacement: 1 to 6.1 cm³ and a wide range of modular lements allowing for further customisation;
• Caproni HC mini power packs: DC motors 1 to 3 kW; 12 or 24 v, tank volume: 2 to 15 l, pump displacement: 1 to 6.1 cm3, working pressure: up to 250 bar and a choice of valve assemblies.

Caproni Motors

• Caproni hydraulics MGL motor: displacement [cm3/rev.] 50 to 315, maximum pressure [bar] 140, maximum oil flow [lpm] 25 to 60, maximum speed 600rpm, maximum torque [daNm] 7.4 to 30.5, minimum speed 10rpm, temperature range [°C] -30 to + 90, viscosity range [mm2/s] 20 to 75;
• MHL motor: displacement [cm3/rev.] 50 to 400, maximum pressure [bar] 175, maximum oil flow [lpm] 60, maximum speed 1200rpm, maximum torque [daNm] 9.4 to 50, temperature range [°C] -30 ÷ 90, viscosity range [mm2/s] 20 to 75;
• DC motor – 81mm: rated powers 0.2 to 1 kW, rated voltages 12, 24v DC, rated speed 1500 to 3000 rpm, protection IP44;
• Caproni DC motor – 112mm: rated powers 1.5 to 2 kW, rated voltages 12, 24v DC, rated speed 2300 to 2700 rpm, protection IP44;
• DC Motor – 125mm: rated power 3 kW, rated voltage 24v DC, rated speed 3500 r.p.m, protection IP44;
• Caproni DC Motor – 200mm: rated powers 5-10 kW, rated voltages 24 -80v DC, rated speed 2400 to 2800 rpm, protection IP21.

Please contact us if you cannot see the Caproni hydraulics equipment that you need – we’ll still be able to help!
