Brooklands Concorde

A Hydraulics Online Case Study

Innovate. Design. Test. Repeat.

We did it again! Brookland Concorde became the third Concorde in the world with a functioning “droop nose”, two of which were in the UK, with Hydraulics Online designing and supplying the hydraulic systems to power both of them…

The Rebuild

When British Airways and Air France retired their fleets in 2003, Brooklands Museum at Weybridge in Surrey accepted Concorde G-BBDG as a museum exhibit. She was dismantled as far as possible, but still had to be cut up into five major sections to enable transportation to Brooklands Museum; the task of structurally disassembling and reassembling the aircraft was undertaken by Air Salvage International.

Delta Golf was then restored by a team of over 100 volunteers from the museum, assisted by students from the University of Surrey.

Three years, and many thousands of man-hours work later, on 26th July 2006, the Brooklands Concorde was opened to the public with the “Concorde Experience” allowing visitors to enter the aircraft and experience a virtual flight at speeds up to Mach 2.

In 2014, having approached Hydraulics Online for assistance two years earlier, a team of fellow enthusiasts and former Concorde engineers – the Heritage Concorde team – successfully restored power to another Concorde’s nose and visor. On display at the Imperial War Museum, Duxford, G-AXDN then became the first UK Concorde to droop her nose since 2003 using a bespoke hydraulic system designed and supplied by Hydraulics Online. (You can read more about this project, Project Salute, here.)

So, we’d done it again; brought an idea to life… made a dream come true! And we couldn’t be prouder. James Cullingham, who led the nose project for the Brooklands Concorde team, thanked Hydraulics Online after the 10th anniversary celebrations succinctly saying: “You supplied exactly what I wanted.”

Whether you have a new idea that you want to prototype, or an existing hydraulic system design that needs improving – we have the knowledge you need. Our hydraulic engineers always relish a challenge, and don’t shy away from fault-finding, diagnostics and solving problems where others may have failed to; it’s all in a day’s work for us.

“You reeled off figures and technical data that were way above my understanding, but explained things very well. You don’t just shift boxes; you know your business inside and out. A very big “thank you” from the whole team –  I hope we can continue the great work.”

Graham CahillProjects Director, Heritage Concorde

More of our work with Heritage Concorde…

Concorde G-AXDN

Duxford Aviation Society, owners of the British Airliner Collection, were keen to improve their display of Concorde 101 G-AXDN at the Imperial War Museum, Duxford.

In response, Heritage Concorde proposed making her the first UK Concorde since 2003 to be able to “droop” her nose. The hydraulic systems on Concorde 101 G-AXDN had not been used since she was retired in 1977 and so the team approached Hydraulics Online asking if we could help on “Project Salute”.

Learn more
Day picture of Concorde G-BOAC in hangar »

Concorde G-BOAC

Concorde G-BOAC, aka “Alpha Charlie”, located at the Manchester Airport Runway Visitor Park, is the third Concorde in the country with a restored moving nose and visor, expertly engineered by our Cheshire-based engineers and the Heritage Concorde team.

The restoration coincided with the celebrations for Concorde’s golden jubilee on 2nd March 2019 – marking 50 years, to the minute, since the first Concorde flight which took off from Toulouse at 13:30 GMT on 2nd March 1969.
